KickAss Quick Connect Low Voltage Disconnect (LVD)
Pickup available at Acacia Ridge Store
Usually ready in 1 hour
1 Year Warranty
This product is covered by a 1 Year Limited Warranty.
Description
KickAss Low Voltage Disconnect – Plug & Play Battery Protection
Safeguard your batteries from over-discharge with this easy-to-use Low Voltage Disconnect (LVD). Designed with Anderson-style connectors, it requires no hardwiring—just plug in and you’re ready to go.
The LVD supplies power to your devices while monitoring battery voltage. An LED indicator displays your battery’s state of charge. When voltage drops to 11V, the device disconnects the load to prevent deep discharge, and only reconnects once voltage climbs back to 13V.
3 Operating Modes:
-
Normal: Disconnects at 11V with a 60-second warning alarm; reconnects at 13V.
-
Alarm Mute: Same as Normal Mode but silences the warning alarm.
-
Override: Bypasses voltage sensing for direct power—use only in emergencies.
Specifications
| Voltage System | 12 Volt |
| Maximum Input / Output Amperage | 50 Amp |
| Standby Input Current | 150 mA |
| Battery Cut-Out Voltage | 11 Volts (or below) |
| Battery Cut-In Voltage | 13 Volts (or above) |
| Battery Cut-Out Time Delay | 60 secs @ < 11 Volts |
| Operating Temperature | 0 - 50°C |
| Net Weight | 0.35kg |
| Housing Dimensions | 110mm x 102mm x 50mm |
| Mounting Hole to Mounting Hole Diameter | L - 49mm / W - 95mm |
